CIRCUITS DIODE

DC HALF WAVE RECTIFIER

Consider the schematic representation of a circuit with a diode. The circuit has a diode, a resistor and a DC source.



In this simulator, you will choose a set of parameters to be typed in the boxes that appear below. The source voltage must be positive.


Source voltage u(t) =  V      Resistance R =  \Omega

Saturation current I_{S} =  A

Diode constant or emission coefficient (n) =   dimentionless with values from 1 to 2

Thermal voltage V_{T} =  V

Transition time t_{T} =  s

Junction capacitance C_{j0} =  F

Junction coefficient m =   dimensionless with values 0.33 (linearly graded junction) or 0.5 (abrupt junction);

Junction voltage V_0 =  V

Submit for computation clicking “Send”. The result will be:

▪ Diode voltage: x_{1}(t)-x_{2}(t)

▪ Resistor voltage: x_{2}(t)

▪ Current “entering” the source: x_{3}(t) (multiply by -1)
