The time responses are computed from the following expressions when different input functions are used.


v_C(t) = h_{VC}(t)*v(t) = \int_{0}^{t} h_{VC}(t - \tau) v(\tau) d \tau = \int_{0}^{t} h_{VC}(\tau) v(t - \tau) d \tau

v_R(t) = h_{VR}(t)*v(t) = \int_{0}^{t} h_{VR}(t - \tau) v(\tau) d \tau = \int_{0}^{t} h_{VR}(\tau) v(t - \tau) d \tau

Impulse Response

R =  Ω     C =  F     Final Time =  s

Response to the Unit Step Function

R =  Ω     C =  F     Final Time =  s

Response to the Sinusoid

R =  Ω     C =  F     Final Time =  s

Frequency =  Hz     Amplitude =
